Key Features
- Construction:
- Tube: Oil- and heat-resistant synthetic rubber
- Reinforcement: High-tensile steel wire braid or spiral layers (as per pressure rating)
- Cover: Abrasion-, oil-, and weather-resistant synthetic rubber
- Temperature Range: -40°C to +100°C (-40°F to +212°F)
- Pressure Rating: Suitable for low, medium, and high-pressure hydraulic systems
- Available Standards: SAE 100R1, R2, R5, R6, R7, R8, R12, R13, and R15
- Sizes Available: ¼” to 2” (custom sizes on request)
- End Fittings: Compatible with a wide range of hydraulic fittings and couplings
Applications
Our hydraulic hose pipes are suitable for conveying hydraulic fluids, lubricating oils, fuel, air, and water under high pressure. They are widely used across industries such as:
- Earthmoving and construction equipment
- Agricultural and forestry machinery
- Material handling and lifting systems
- Industrial hydraulic presses and power units
- Automotive and transport hydraulic systems
- Marine and mining applications
Advantages of CALCUTTA HYDRAULICS Hydraulic Hose Pipes
- Durable construction for long-lasting performance
- High resistance to oil, abrasion, and weathering
- Flexible and easy to install in tight routing conditions
- Compatible with standard hydraulic fluids
- Leak-proof assemblies when used with our precision hydraulic fittings
- Custom hose assemblies available as per client specifications
